Accsoon CineView M7-7" 4K HDR Director Monitor with Pro Color Accuracy
Key Features：
- 7-inch 4K HDR director monitor with cinema-grade color accuracy.
- Ultra-bright 1000 nits screen with 1000:1 contrast for outdoor shooting.
- CineView M7 runs on a smooth Android system, allowing users to install apps for expanded monitoring, control, and workflow flexibility on set.
- Supports 4K/1080P input via HDMI®/SDI with real-time format conversion.
- Wired monitoring, 4K recording, and SRT/RTMP live streaming made easy.
- Supports real-time video format conversion across HDMI® and SDI signals, handling resolutions up to 4K DCI/UHD (4096×2160 / 3840×2160) at up to 60fps, and down-converting to 1080p/720p for flexible monitoring across multiple devices.
- On-screen tools including focus peaking, waveforms, false color, and LUTs.
- Flexible power options: NP-F batteries, DC input, or USB-C PD.
- Lightweight 476 g portable design, ideal for on-the-go filming.
Our Services & Guarantees
Free shipping on all orders. Delivery time varies by region.
All products are covered by a one-year manufacturer warranty.
Return or exchange within 7 days if you’re not satisfied.
Our team is here to help with setup, usage, and troubleshooting.
Secure Payment Methods
Accsoon CineView M7
$799.00
Let’s take a closer look.
Cinema Grade Color Accuracy
High Bright Fully-Laminated Low Reflection Screen
The future of smart
monitoring is here
monitoring is here
Compatibility with CineView Systems*
DCI 4K60 Input&Output
Efficient Color Grading and Management
Advanced Monitoring
Features
Features
Frame Rate & Resolution
Conversion
Conversion
Versatile I/0
Built-in WiFi for Live Streaming,Camera to Cloud
Instant Record and Playback
Camera Control*
Edge-Lit Backlight System, for Precise Bright & Dark Control
Achieving high brightness is easy, but maintaining accurate colors is challenging. CineView M7 series features a 1000:1 ultra-high
contrast ratio combined with a fully laminated high-transmittance display, effortlessly handling both dark and bright scenes. Built with Edge-Lit backlight
system with intelligent brightness control enables pixel-level precision, delivering true-to-life color reproduction without distortion.
contrast ratio combined with a fully laminated high-transmittance display, effortlessly handling both dark and bright scenes. Built with Edge-Lit backlight
system with intelligent brightness control enables pixel-level precision, delivering true-to-life color reproduction without distortion.
High Bright Fully Laminated Display - True Colors Under Direct Sunlight
CineView M7 series is equipped with high transparency screen,enhanced by exclusiveDXC coating,increasing light transmittance to
99%while significantly reducing reflectivity. Even in bright outdoor environments,the screen maintains exceptional clarity and color accuracy.
99%while significantly reducing reflectivity. Even in bright outdoor environments,the screen maintains exceptional clarity and color accuracy.
All in One Wireless Workstation
CineView M7 Series features integrated long-range wireless video transmitter and receiver capabilities,
seamlessly connecting to any Accsoon CineView transmitter. It leverages
Accsoon’s patented Dual-Band transmission technology for ultra-low latency wireless monitoring. Nail every shot with cinematic grade
tools like LUT box, false color and waveforms-all controlled through customizable buttons.
Accsoon’s patented Dual-Band transmission technology for ultra-low latency wireless monitoring. Nail every shot with cinematic grade
tools like LUT box, false color and waveforms-all controlled through customizable buttons.
Camera Control
Record Trigger
Responsive Touch Focus
Seamless Control Access
Supports IP Connection
Simultaneously and bi-directional record on the camera, as well as the monitor.
AF touch focus works in any zone, just tap to shift focus or drag the box to follow your subject.
The main parameter control menu brings up shutter speed, aperture, sensitivity (ISO) and white balance options in the top status bar of the monitor.
Currently only available for the Sony FX6.
Seamless Interaction, everything under your control
One Step Ahead Redefining Smart Monitoring
CineView M7 Series powered by 8K high-performance processors and a smart operating system,
is designed to adapt to the evolving needs of modern production.
Smart Evolution: Your Portable Production Workstation
Smart Evolution: Your Portable Production Workstation
Specifications
| Display screen | 7” LCD |
| Resolution | 1920 × 1080 pixels |
| PPI | 323 |
| Aspectratio | 16:9 |
| Brightness | 1000 nits |
| Contrast ratio | 1000:1 |
| Viewing angle | 176°/176° |
| Backlight type | Edge-Lit Ultra-transparent LED Backlight |
| Screen color calibration | Supported |
| LUT | 1D and 3D Cube LUTs Supported 1D: up to 4096 points 3D: up to 127 points |
| Video input port | HDMI® 2.0/3G-SDI |
| Video output port | HDMI® 2.0/3G-SDI |
| HDMI® videoinput format | 4K DCI (4096×2160): 23.98/24/25/29.97/30/50/59.94/60 4K UHD (3840×2160): 23.98/24/25/29.97/30/50/59.94/60 1080p: 23.98/24/25/29.97/30/50/59.94/60 1080i: 50/59.94/60 720p: 50/59.94/60 |
| SDI video input format | 1080p: 23.98/24/25/29.97/30/50/59.94/60 Level A/B 1080i: 50/59.94/60 |
| HDMI® video output format | 4K DCI (4096×2160): 23.98/24/25/29.97/30/50/59.94/60 4K UHD (3840×2160): 23.98/24/25/29.97/30/50/59.94/60 1080p: 23.98/24/25/29.97/30/50/59.94/60 1080i: 50/59.94/60 720p: 50/59.94/60 |
| SDI video output format | 1080p: 23.98/24/25/29.97/30/50/59.94/60 Level A 1080i: 50/59.94/60 |
| DC port | 6.0~16.8V 5.5mm×2.1mm Center Positive |
| Compatible battery | Compatible with NP-F550, NP-F750, NP-F970 Batteries |
| USB-C power input port | PD3.0 9V/3A, 12V/3A, 15V/3A |
| USB-Cpower output port | Maximum: 5V/2A |
| Microphone jack | 3.5mm TRS |
| Headphone jack | 3.5mm CTIA |
| Microphone input audio sampling | 16bit, 48KHz |
| Power consumption | 12W~28W（Varies according to actual usage） |
| Housing | Aircraft-grade Aluminium Alloy |
| Heatdissipation | Active + Passive Cooling |
| Work environment temperature | -10~40℃ |
| Weight (antennas excluded) | 476g |
| Dimensions (antennas excluded) | 182.2×120.7×31.5mm |
Product Comparison
CineView M7
|
CineView M7 Pro
|
CineView M7H Pro
|
|
|---|---|---|---|
| Display | 7-inch Touchscreen Color Calibration 3D/1D LUT Support |
7-inch Touchscreen Color Calibration 3D/1D LUT Support |
7-inch Touchscreen Color Calibration 3D/1D LUT Support |
| Monitoring Tools | Professional Monitoring Tools Anamorphic Display Mode Custom Background Image |
Professional Monitoring Tools Anamorphic Display Mode Custom Background Image |
Professional Monitoring Tools Anamorphic Display Mode Custom Background Image |
| Wireless Transmission | ❌ | TX & RX | TX & RX |
| Wireless Transmission Distance | ❌ | 350m | 350m |
| HDMI® Video Input/Output | DCI 4K60 | DCI 4K60 | DCI 4K60 |
| SDI Video Input/Output | 1080P | 1080P | ❌ |
| Signal Conversion | SDI & HDMI® Cross Conversion | SDI & HDMI® Cross Conversion | ❌ |
| Resolution Range | 720P–4K | 720P–4K | 720P–4K |
| Camera Control | Bi-directional Record Trigger Aperture Control Shutter Speed/Angle White Balance & Touch Focus ISO/EI |
Bi-directional Record Trigger Aperture Control Shutter Speed/Angle White Balance & Touch Focus ISO/EI |
Bi-directional Record Trigger Aperture Control Shutter Speed/Angle White Balance & Touch Focus ISO/EI |
| Operating System | Android OS | Android OS | Android OS |
| Live Streaming | ✅ | ✅ | ✅ |
